SCHATTELLO – The centre pole parasol for the hospitality industry
SCHATTELLO is the perfect large parasol for the catering trade and other commercial applications. Whether large-scale sun protection in a street café, stylish shading for outdoor catering, elegant roofing of public areas at trade fairs or events, as a round parasol, rectangular parasol, square parasol or triangular parasol - SCHATTELLO is the right parasol for high professional demands.
The advantages and benefits for you
- Optimal use of your outdoor area/patio, with models that come in 38 different sizes (round, square, rectangular, triangular, eccentric)
- Round parasol with an area of up to 409 ft², or a square parasol up to 269 ft²
- Centre pole parasol with all-weather protection function
- Telescopic pole (opening and closing above the table height of many seating arrangements)
- High level of wind safety, verified in accordance with the standards DIN 1055:2005 and EN 1991-1-1:2011-2014
- Excellent UV protection of UPF40 to UPF80 in accordance with the standard UV801
- The entire parasol fabric collection has been fully tested in accordance with UV801
- Durable and robust parasol ribs (aluminium parasols), all parts available to purchase as spares
- Frame made of high-quality, extruded aluminium alloy profiles, made in Europe
- Hardwearing corrosion protection provided by polyester powder coating
- High-quality bevel gears with automatic brake integrated on the inside
- Canopy with a hardwearing and self-tensioning telescopic spring system
- The canopy is quick and easy to replace
- Three different valance versions
- All parts optimised for care and maintenance
- Extremely sturdy and durable
- The parasol canopy and valance can be printed (screen print and digital print)
- Extensive accessories (see below)
- Delivered ready to set up
- All parts available for purchase as spares and for repair there and then
SCHATTELLO 16' 5" x 16' 5"
SCHATTELLO Ø 16' 5"
SCHATTELLO 13' 1" x 19' 8"
SCHATTELLO 16' 5" x 16' 5"
SCHATTELLO 3,0 x 4,0 m
SCHATTELLO 9' 10" x 13' 1"
SCHATTELLO 16' 5" x 16' 5"
SCHATTELLO 14' 9" x 14' 9"
SCHATTELLO 13' 1" x 19' 8"
SCHATTELLO 13' 1" x 13' 1"
SCHATTELLO 9' 10" x 13' 1" & SCHATTELLO 13' 1" x 19' 8"
SCHATTELLO 13' 1" x 13' 1"
SCHATTELLO 9' 10" x 16' 5"
SCHATTELLO 14' 9" x 14' 9"
SCHATTELLO 5.0 m round
SCHATTELLO 3.5 x 4.0
SCHATTELLO 9' 10" x 13' 1"
SCHATTELLO 3.0 x 4.0 m
SCHATTELLO 14' 9" x 14' 9"
SCHATTELLO 16' 5" x 16' 5"
SCHATTELLO 16' 5" x 16' 5"
SCHATTELLO 13' 1" x 13' 1"
SCHATTELLO 16' 5" x 16' 5"
SCHATTELLO 4.0 x 4.0 m and 3.0 x 4.0 m
SCHATTELLO 3,0 x 3.0 m und 4,0 x 4,0 m
SCHATTELLO 9' 10" x 16' 5"
SCHATTELLO 4.0 x 4.0 m
SCHATTELLO 4,5 x 4,5 m
SCHATTELLO 9' 10" x 9' 10"
SCHATTELLO 3,0 x 3,0 m
SCHATTELLO 3.0 x 3.0m eccentric
SCHATTELLO 8' 2" x 16' 5" & 9' 10" x 9' 10" eccentric
SCHATTELLO 13' 1" x 13' 1"
SCHATTELLO 16' 5" x 16' 5"
SCHATTELLO 13' 1" x 13' 1"
SCHATTELLO 2,5 x 2,5 m
SCHATTELLO Ø 19' 8"
SCHATTELLO 5,0 x 5,0 m & 4,0 x 4,0 m
SCHATTELLO 2.0 x 4.0 m
SCHATTELLO 11' 6" x 11' 6"
SCHATTELLO 13' 1" x 13' 1"
SCHATTELLO 13' 1" x 13' 1"
SCHATTELLO 3.5 x 3.5 m
SCHATTELLO 4,5 x 4,5 m
SCHATTELLO 3.5 x 3.5 m
SCHATTELLO 14' 9" x 14' 9"
SCHATTELLO 4.0 x 4.5 m
SCHATTELLO 16' 5" x 16' 5"
SCHATTELLO 16' 5" x 16' 5"
SCHATTELLO 4.0 x 4.0 m
SCHATTELLO 4,0 x 5,0 m
SCHATTELLO Ø 4 m
SCHATTELLO 3,0 x 3,0 m
SCHATTELLO 13' 1" x 13' 1"
Product details
The fact that SCHATTELLO has been such a successful model is no coincidence, as real professionals played a role in the production of this classic among parasols for the hospitality industry. The outcome: The quality brand MAY.
1Fabric type and fabric colours
Choose from more than 70 trendy textile designs that are available in three different fabric types:- MayTex Poly, 230 g/m², water column > 1,000 mm
- MayTex Acryl, 300 g/m², water column 370 mm
- MayTex PVC, 480 g/m², water column > 1,000 mm
- Other colours and types of fabric are available any time upon request
- Textiles with fire rating (A or B1) upon request
- All fabrics are manufactured in Europe
You can find more information under Colours & Fabrics.
Choose from more than 70 trendy textile designs that are available in three different fabric types:
You can find more information under Colours & Fabrics.
- MayTex Poly, 230 g/m², water column > 1,000 mm
- MayTex Acryl, 300 g/m², water column 370 mm
- MayTex PVC, 480 g/m², water column > 1,000 mm
- Other colours and types of fabric are available any time upon request
- Textiles with fire rating (A or B1) upon request
- All fabrics are manufactured in Europe
You can find more information under Colours & Fabrics.
2Operation
The large parasol can be operated in three different ways- Hand crank
- Cordless drill (to a limited extent)
- Tubular motor (optional)
The large parasol can be operated in three different ways
- Hand crank
- Cordless drill (to a limited extent)
- Tubular motor (optional)
3Valance versions
Parasol canopy ‘1’ features a classic valance. A valance is a good idea when adding rain gutters, side panels and your logo. Version ‘2’ does not come with a valance. This makes an understated and modern impression, not only for use at home.
Parasol canopy ‘1’ features a classic valance. A valance is a good idea when adding rain gutters, side panels and your logo. Version ‘2’ does not come with a valance. This makes an understated and modern impression, not only for use at home.
4The parasol frame
The frame is produced using very high-quality extruded aluminium alloy profiles.- Parasol pole Ø 76 × 3 mm
- Spoke dimensions 35 × 20 × 2 mm
- Support rail dimensions 30 × 20 × 2 mm
The frame is produced using very high-quality extruded aluminium alloy profiles.
- Parasol pole Ø 76 × 3 mm
- Spoke dimensions 35 × 20 × 2 mm
- Support rail dimensions 30 × 20 × 2 mm
5Connecting elements
We place particular value on meticulous workmanship, which is why all moving axes are secured using bolts that can be removed. This complex manufacturing process guarantees maximum stability and durability, and ensures ease of handling in the event of any repairs.
We place particular value on meticulous workmanship, which is why all moving axes are secured using bolts that can be removed. This complex manufacturing process guarantees maximum stability and durability, and ensures ease of handling in the event of any repairs.
6The canopy
The self-tensioning telescopic spring system keeps the canopy taut even after years of use, and can absorb dynamic wind loads. The canopy is easy to replace in combination with the stainless steel hooks.
The self-tensioning telescopic spring system keeps the canopy taut even after years of use, and can absorb dynamic wind loads. The canopy is easy to replace in combination with the stainless steel hooks.
7Reinforced spokes
The elegant spokes have been reinforced in the areas subject to particularly high loads by integrating a steel core inside them.
The elegant spokes have been reinforced in the areas subject to particularly high loads by integrating a steel core inside them.
8Wind tunnel test
Tests conducted in a wind tunnel allowed us to provide proof of the stability and high level of stability of our parasols. Even wind speeds of 65 km/h were unable to make an impression on a parasol measuring 14' 9" × 14' 9".
Tests conducted in a wind tunnel allowed us to provide proof of the stability and high level of stability of our parasols. Even wind speeds of 65 km/h were unable to make an impression on a parasol measuring 14' 9" × 14' 9".
9The frame coating
The surface of the frame is powder coated, extremely impact and shock resistant, and available in the following colours:Standard colours:
- RAL 9010 pure white
- RAL 9006 white aluminium
Custom colours at no extra charge:
- RAL 8019 grey-brown
- RAL 7016 anthracite grey with fine texture
Other custom colours are available for a surcharge.
The surface of the frame is powder coated, extremely impact and shock resistant, and available in the following colours:
Standard colours:
Custom colours at no extra charge:
Other custom colours are available for a surcharge.
Standard colours:
- RAL 9010 pure white
- RAL 9006 white aluminium
Custom colours at no extra charge:
- RAL 8019 grey-brown
- RAL 7016 anthracite grey with fine texture
Other custom colours are available for a surcharge.
10The top plate
Elegant, attractive and detachable. Colour harmonises with the frame coating.
Elegant, attractive and detachable. Colour harmonises with the frame coating.
11When not in use
When the weather’s not good, the protective cover provided is easy to slide over the parasol.
When the weather’s not good, the protective cover provided is easy to slide over the parasol.
12Assembly
Pull the parasol out of the cardboard sleeve, remove the packaging materials, place the parasol in the base and you’re done – it only takes a few minutes.Pull the parasol out of the cardboard sleeve, remove the packaging materials, place the parasol in the base and you’re done – it only takes a few minutes.
13The operating manual
Proper handling of the product ensures a long service life. Reap the profit of our 30 years of experience:PDF file to download:
SCHATTELLO without locking hinge Operating manual
SCHATTELLO with locking hinge Operating manual
Proper handling of the product ensures a long service life. Reap the profit of our 30 years of experience:
PDF file to download:
SCHATTELLO without locking hinge Operating manual
SCHATTELLO with locking hinge Operating manual
PDF file to download:
SCHATTELLO without locking hinge Operating manual
SCHATTELLO with locking hinge Operating manual
Technical data
SCHATTELLO - 3.00 Metres - Round
| Shape | Round | |
| Dimensions | Ø 3.00 m | |
| Segments | 8 panels | |
| Area | 6.4 m² | |
| X | Distance from centre pole to outer edge of canopy | cm |
| A | Height when closed incl. top plate | 355 cm |
| B | Height when opened incl. top plate | 304 cm |
| C | Headroom with valance | 212 cm |
| D | Headroom without valance from spoke edge | 237 cm |
| A1D1 | Ground clearance from spoke edgelower spoke edge of spokes A1 or D1 | cm |
| F | Ground clearance from spoke edge | 193 cm |
| E | Valance height | 28 cm |
| G | Height of lower distribution flange | 227 cm |
| H | Crank height | 92 cm |
| D2 | cm | |
| A2C2 | cm | |
| B1C1 | cm | |
| B2 | cm | |
| Diameter of parasol pole | Ø 7.6 cm | |
| Pole thickness | 0.3 cm | |
| Weight without packaging MayTex-Acryl without valance | 26 kg | |
| Length of packaging cardboard sleeve Ø 33 cm | 444 cm | |
| Weight of packaging | 17 kg | |
| Foundation length/width/minimum depth | 50 / 50 / 60 cm | |
| Minimum ballast number of concrete slab layers XZ49 | 1 x ~ 112 kg |
All information about heights refer to parasols with a MayTex Acryl canopy and which are set up in an anchor tube (SZ118, SZ146, SZ150). Dimensions for other means of securing parasols change as follows:
| Full frame pedestal | SZ201 | + 5.5 in |
| Full frame pedestal | SZ203 | + 6.7 in |
| Full frame pedestal | SZ205 | + 8.3 in |
| Full frame pedestal | SZ411 | + 3.5 in |
| Full frame pedestal | SZ412 | + 4.7 in |
| Full frame pedestal | SZ414 | + 6.3 in |
| Full frame pedestal | SZ420 | + 7.5 in |
| Anchor plate | SZ131 | + 0.6 in |
| Anchor plate | SZ261 | + 0.6 in |
| Base plate | SZ272 | + 1.6 in |
| Base plate | SZ273 | + 1.6 in |
| Base plate | SZ274 | + 1.6 in |
| Base plate | SZ275 | + 1.6 in |
Intermediate dimensions and custom sizes upon request. Dimensional tolerances ±5%.
3D image of a foundation with a winter cover. Create a frost-proof foundation and increase its size accordingly if the ground is poor.
