FILIUS – The small parasol that’s big in quality
FILIUS is the smallest of our centre pole parasols. This parasol for the hospitality industry and retail use is only small when it comes to its dimensions – in terms of quality, convenience of use, design and stability, in contrast, the FILIUS is a top performer in our parasol collection.
The advantages and benefits for you
- Optimal use of your outdoor area/patio, with models that come in 10 different sizes (round, square, rectangular)
- Round parasol with an area of up to 118 ft², or a square parasol up to 129 m²
- Available with a cable pull and crank lift
- Can be moved, and is easy to transport, with the right parasol bases
- Centre pole parasol (not telescopic) with all-weather protection function
- Suitable to be set up and taken down every day. The low weight makes it easy to carry, and it can be moved using the wheeled pedestals
- Excellent UV protection of UPF40 to UPF80 in accordance with the standard UV801
- The entire parasol fabric collection has been fully tested in accordance with UV801
- Durable and robust parasol ribs (aluminium parasols), all parts available to purchase as spares
- Frame made of high-quality, extruded aluminium alloy profiles, made in Europe
- Hardwearing corrosion protection provided by polyester powder coating
- Canopy with a hardwearing and self-tensioning telescopic spring system
- The canopy is quick and easy to replace
- Three different valance versions
- Also available in a model with a ‘pagoda parasol’ design
- All parts optimised for care and maintenance
- Extremely sturdy and durable
- The parasol canopy and valance can be printed (screen print and digital print)
- Extensive accessories (see below)
- Delivered ready to set up
- All parts available for purchase as spares and for repair there and then
FILIUS 9' 10" x 9' 10"
FILIUS 2,0 x 2.0 m und 2,25 x 3,05 m
FILIUS 8' 2" x 8' 2"
FILIUS 2,5 x 2,5 m
FILIUS ∅ 3.0 m
FILIUS 9' 10" x 9' 10"
FILIUS 2,0 x 2.0 m and 2,25 x 3,05 m
FILIUS Ø 2.5 m
FILIUS 9' 10" x 9' 10"
FILIUS Ø 9' 10"
FILIUS 3,5 x 3,5 m
FILIUS 9' 10" x 9' 10"
FILIUS 3,0 x 3,0 m
FILIUS Ø 2,5 m
FILIUS 9' 10" x 9' 10"
FILIUS Ø 3,0 m
Product details
Its lightness makes FILIUS a particularly popular way to provide protection from the sun at outdoor cafés, at markets, as a shelter at events, or for use for decorative purposes. FILIUS is, of course, also an attractive parasol for use in the garden or on the patio at home. The centre pole parasol FILIUS is optionally available with a cable pull (FILIUS FS) or with a crank lift (FILIUS FK).
1Fabric type and fabric colours
Choose from more than 70 trendy textile designs that are available in three different fabric types:- MayTex Poly, 230 g/m², water column > 1,000 mm
- MayTex Acryl, 300 g/m², water column 370 mm
- MayTex PVC, 480 g/m², water column > 1,000 mm
- Other colours and types of fabric are available any time upon request
- Textiles with fire rating (A or B1) upon request
- All fabrics are manufactured in Europe
You can find more information under Colours & Fabrics.
Choose from more than 70 trendy textile designs that are available in three different fabric types:
You can find more information under Colours & Fabrics.
- MayTex Poly, 230 g/m², water column > 1,000 mm
- MayTex Acryl, 300 g/m², water column 370 mm
- MayTex PVC, 480 g/m², water column > 1,000 mm
- Other colours and types of fabric are available any time upon request
- Textiles with fire rating (A or B1) upon request
- All fabrics are manufactured in Europe
You can find more information under Colours & Fabrics.
2Operation
FILIUS is available in one of two models, either with a cable pull (FS) or with a crank lift (FK).
FILIUS is available in one of two models, either with a cable pull (FS) or with a crank lift (FK).
3Valance versions
Parasol canopy ‘1’ features a classic valance. A valance is a good idea when adding side panels and a print showing your logo. Version ‘2’ does not come with a valance. This makes an understated and modern impression, not only for use at home.
Parasol canopy ‘1’ features a classic valance. A valance is a good idea when adding side panels and a print showing your logo. Version ‘2’ does not come with a valance. This makes an understated and modern impression, not only for use at home.
4Canopy bonnet
This optional fabric version features an airy, Mediterranean character.
This optional fabric version features an airy, Mediterranean character.
5Pagoda parasol design
The FILIUS with a pagoda-style canopy is an opulent designer parasol that stands out from other parasols. The pagoda system makes it seem like the canopy is fluttering overhead, creating an airy and light impression.
The FILIUS with a pagoda-style canopy is an opulent designer parasol that stands out from other parasols. The pagoda system makes it seem like the canopy is fluttering overhead, creating an airy and light impression.
6The parasol frame
The frame is produced using very high-quality extruded aluminium alloy profiles.- Parasol pole Ø 55 × 2.5 mm
- Spoke dimensions 30 × 15 × 2 mm / 25 × 15 × 2 mm
- Support rail dimensions 25 × 15 × 2 mm
The frame is produced using very high-quality extruded aluminium alloy profiles.
- Parasol pole Ø 55 × 2.5 mm
- Spoke dimensions 30 × 15 × 2 mm / 25 × 15 × 2 mm
- Support rail dimensions 25 × 15 × 2 mm
7Connecting elements
We place particular value on meticulous workmanship, which is why all moving axes are secured using bolts that can be removed. This complex manufacturing process guarantees maximum stability and durability, and ensures ease of handling in the event of any repairs.
We place particular value on meticulous workmanship, which is why all moving axes are secured using bolts that can be removed. This complex manufacturing process guarantees maximum stability and durability, and ensures ease of handling in the event of any repairs.
8The Canopy
The self-tensioning telescopic spring system keeps the canopy taut even after years of use, and can absorb dynamic wind loads. The canopy is easy to replace in combination with the stainless steel hooks.
The self-tensioning telescopic spring system keeps the canopy taut even after years of use, and can absorb dynamic wind loads. The canopy is easy to replace in combination with the stainless steel hooks.
9Reinforced spokes
The elegant spokes have been reinforced in the areas subject to particularly high loads by integrating a steel core inside them.
The elegant spokes have been reinforced in the areas subject to particularly high loads by integrating a steel core inside them.
10The frame coating
The surface of the frame is powder coated, extremely impact and shock resistant, and available in the following colours:Standard colours:
- RAL 9010 pure white
- RAL 9006 white aluminium
Custom colours at no extra charge:
- RAL 8019 grey-brown
- RAL 7016 anthracite grey with fine texture
Other custom colours are available for a surcharge.
The surface of the frame is powder coated, extremely impact and shock resistant, and available in the following colours:
Standard colours:
Custom colours at no extra charge:
Other custom colours are available for a surcharge.
Standard colours:
- RAL 9010 pure white
- RAL 9006 white aluminium
Custom colours at no extra charge:
- RAL 8019 grey-brown
- RAL 7016 anthracite grey with fine texture
Other custom colours are available for a surcharge.
11The top plate
Elegant, attractive and detachable. Colour harmonises with the frame coating.
Elegant, attractive and detachable. Colour harmonises with the frame coating.
12When not in use
When the weather’s not good, the protective cover provided is easy to slide over the parasol. There’s a fixed rod sewn into the protective cover to make it easy to use, and a zip has been integrated as well.
When the weather’s not good, the protective cover provided is easy to slide over the parasol. There’s a fixed rod sewn into the protective cover to make it easy to use, and a zip has been integrated as well.
13Assembly
Pull the parasol out of the cardboard box, remove the packaging materials, place the parasol in the base and you’re done – it only takes a few minutes.Pull the parasol out of the cardboard box, remove the packaging materials, place the parasol in the base and you’re done – it only takes a few minutes.
14The operating manual
Proper handling of the product ensures a long service life. Reap the profit of our 30 years of experience:PDF file to download:
FILIUS operating manual
FILIUS with pagoda operating manual
Proper handling of the product ensures a long service life. Reap the profit of our 30 years of experience:
PDF file to download:
FILIUS operating manual
FILIUS with pagoda operating manual
PDF file to download:
FILIUS operating manual
FILIUS with pagoda operating manual
Technical data
FILIUS - 1.5 x 1.5 Metres - Square
| Shape | Square | |
| Dimensions | Ø 1.5 x 1.5 m | |
| Segments | 4 panels | |
| Area | 2.3 m² | |
| A | Height when closed with valance | 259 cm |
| B | Height when closed without valance | 259 cm |
| C | Headroom with valance | 200 cm |
| D | Headroom without valance from spoke edge | 220 cm |
| E | Valance height | 18 cm |
| F | Ground clearance (with valance) from spoke edge | 148 cm |
| G | Ground clearance (without valance) from spoke edge | 148 cm |
| H | Crank height | 92 cm |
| Diameter of parasol pole | Ø 5.5 cm | |
| Pole thickness | 0.25 cm | |
| Weight without packaging MayTex-Acryl without valance | 15 kg | |
| Length of packaging cardboard sleeve Ø 25 cm | 307 cm | |
| Weight of packaging | 7.5 kg | |
| Foundation length/width/minimum depth | 50 / 50 / 60 cm | |
| Minimum ballast number of concrete slab layers XZ49 | 1 x ~ 72 kg |
All information about heights refer to parasols with a MayTex Acryl canopy and which are set up in an anchor tube (DMZ118, DMZ146, DMZ150). Dimensions for other means of securing parasols change as follows:
| Cross pedestal | DMZ110 | + 2.4 in |
| Full frame pedestal | DMZ411 | + 3.5 in |
| Full frame pedestal | DMZ412 | + 4.7 in |
| Full frame pedestal | DMZ414 | + 6.3 in |
| Full frame pedestal | DMZ420 | + 7.5 in |
| Granite base | DMZ141 | + 3.9 in |
| Wheeled pedestal | DMZ282 | + 5.5/5.9 in |
| Anchor plate | DMZ261 | + 1.6 in |
| Base plate | DMZ271 | + 4.7 in |
Intermediate dimensions and custom sizes upon request. Dimensional tolerances ±5%.
3D image of a foundation with a winter cover. Create a frost-proof foundation and increase its size accordingly if the ground is poor.
